GIGABYTE INTEL® # B760M A E WF6E GEN5, LGA1700, 4 x DDR5 DIMM, 4 x SATA 6Gb/s

GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard

The GIGABYTE B760M DS3H WIFI6E GEN5 mATX Motherboard is a powerful and compact option for gamers, creators, and professionals seeking modern capabilities without sacrificing stability or performance. Built with the Intel B760 Express chipset, it supports 14th, 13th, and 12th Generation Intel Core, Pentium Gold, and Celeron CPUs via the LGA1700 socket, making it ideal for a variety of designs. Memory support is future-ready, with four DDR5 DIMM ports supporting up to 256GB capacity and overclocking rates of up to DDR5-7600 when combined with high-end processors. The GIGABYTE B760M DS3H WIFI6E GEN5 Motherboard also supports dual-channel architecture, ECC and non-ECC modules, and Intel XMP profiles for smooth overclocking. Graphics are handled by integrated Intel HD Graphics, which supports HDMI 2.1 with resolutions of up to 4K at 60Hz and multiple DisplayPort outputs, allowing for triple-display setups for productivity and enjoyment. The Realtek codec improves audio quality by enabling up to 7.1-channel HD sound with S/PDIF output, providing an immersive experience. With Realtek 2.5GbE LAN and Intel Wi-Fi 6E AX210 module, the GIGABYTE B760M DS3H WIFI6E GEN5 Motherboard provides Wi-Fi 6E connection across 2.4GHz, 5GHz, and 6GHz bands, as well as Bluetooth 5.3 for current wireless devices. Storage options include two M.2 PCIe 4.0 x4 connectors for NVMe SSDs and four SATA 6Gb/s ports with RAID 0, 1, 5, and 10 support, allowing for high-speed and redundant storage configurations. Expansion is robust, with one PCIe 5.0 x16 port for next-generation GPUs and two PCIe 3.0 x1 slots for add-on cards. The GIGABYTE B760M DS3H WIFI6E GEN5 Motherboard's rear panel features USB 3.2 Gen2 Type-C, USB 3.2 Gen1, USB 2.0, HDMI, DisplayPort, RJ-45 LAN and audio ports, as well as Wi-Fi antenna connectors. Other features include RGB and ARGB headers, Q-Flash Plus for simple BIOS updates, fan monitoring, Smart Backup, and support for GIGABYTE Control Center software. With Windows 10 and 11 compatibility and a micro ATX form factor of 24.4cm x 24.4cm, the GIGABYTE B760M DS3H WIFI6E GEN5 is a dependable motherboard that combines performance, connectivity, and expandability for modern PC designs.
