GIGABYTE INTEL® # B860M D3HP, LGA1851, 2*PCIe 4.0 x4 M.2 Connectors, 4 x DDR5 DIMM , 4 x SATA 6Gb/s

Gigabyte B860M D3HP LGA1851 Micro ATX Motherboard

The Gigabyte B860M D3HP is a high-performance LGA1851 Micro ATX motherboard that supports Intel Core Ultra CPUs. Built with the Intel B860 Express chipset, it can support up to 256GB of DDR5 memory at rates of up to 9066 MT/s when overclocked, resulting in improved multitasking and faster data processing. The Gigabyte LGA1851 Motherboard, with dual-channel memory architecture and compatibility with ECC and non-ECC unbuffered DIMM modules, provides versatility for a variety of computing requirements. This Gigabyte B860M D3HP LGA1851 Motherboard has integrated Intel HD Graphics support, with an HDMI connector capable of 4K resolution at 60Hz and a DisplayPort that supports 3840x2160 at 144Hz, resulting in smooth and sharp images. The Gigabyte B860M D3HP LGA1851 Motherboard includes two M.2 connectors for PCIe 4.0 SSDs and four SATA 6Gb/s ports with RAID 0, 1, 5, and 10 compatibility, ensuring fast data transfer and secure storage options. The Gigabyte B860M D3HP LGA1851 Micro ATX Motherboard's expansion slots offer one PCIe 5.0 x16 slot for a dedicated GPU or NVMe SSD and two PCIe 3.0 x1 slots for extra peripherals. Realtek GbE LAN provides dependable networking, and many USB ports, including a USB Type-C port with USB 3.2 Gen 1 capability. The Gigabyte B860M D3HP LGA1851 Micro ATX Motherboard features Realtek high-definition audio and supports up to 7.1-channel sound for an immersive audio experience. The I/O panel supports HDMI, DisplayPort, USB 3.2 Gen 1, USB 2.0, and a PS/2 keyboard/mouse connector for historical compatibility.
