Product ID: GIG-LGA1700-21·GIGABYTE
Model: H610M K DDR5
Supported CPU: 14th/13th/12th Gen Intel Processors (LGA1700)
Supported RAM: 2x DDR5, Max 128GB 5333(OC)
Graphics Output: 1x HDMI 2.1, 1 x DisplayPort
Features: Realtek GbE LAN chip (1 Gbps/100 Mbps/10 Mbps)
EMI starts from ৳ 858/month
Share this product
. Prices in ৳ are display-only and are not a charge.
| Basic Information | Supported CPU | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel® Core, Pentium Gold and Celeron Processors L3 cache varies with CPU (Please refer "CPU Support List" for more information.) |
|---|---|---|
| Chipset | Intel H610 Express Chipset | |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 | |
| Form Factor | Micro ATX Form Factor; 23.0cm x 21.5cm | |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out | |
| Expansion Slots | PCI | CPU: - 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 Chipset: - 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1 |
| Memory | Type | DDR5 |
| Slots | 2 x DIMM sockets | |
| Supported Memory | Support for 5600/5200/4800/4400 MT/s memory modules 13th Generation Intel Core i5/i3 and 12th Generation Intel Core, Pentium Gold and Celeron Processors: 4800/4400 MT/s memory modules Dual channel memory architecture Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memor | |
| Maximum Memory | Supporting up to 128 GB (64 GB single DIMM capacity) of system memory |
The GIGABYTE H610M K DDR5 Micro ATX motherboard is a compact and versatile platform designed to support the latest Intel processors, including the 14th, 13th, and 12th Gen CPUs with an LGA1700 socket. It provides robust performance and future-proofing for various computing needs, from gaming to content creation. This motherboard supports up to 4x DDR5 DIMMs, allowing for a maximum memory capacity of 64GB at speeds up to 3200 MHz, utilizing Dual Channel Non-ECC Unbuffered memory architecture. The GIGABYTE H610M K DDR5 features a single HDMI 2.1 port for high-definition graphics output and is equipped with a Realtek GbE LAN chip that supports up to 1 Gbps network speeds, with additional support for 100 Mbps connections and bandwidth management capabilities. It offers fast storage options through an NVMe PCIe 3.0 x4 M.2 slot, reducing load times for applications and games. High-quality audio capacitors and an audio noise guard ensure clear and immersive sound quality, enhancing the overall user experience. For efficient cooling and noise management, the Smart Fan 6 feature includes multiple temperature sensors and hybrid fan headers with a fan stop function. The motherboard also comes with the GIGABYTE APP Center, a user-friendly interface for managing system settings and features. Designed for durability, the GIGABYTE H610M K DDR5 incorporates an Anti-Sulfur resistor design, enhancing the longevity and reliability of the components. This motherboard is an excellent choice for building a high-performance PC with the latest technology and features.
In Bangladesh, you can get the original GIGABYTE H610M K DDR5 Micro ATX Motherboard From Technohouse. We have a large collection of the latest GIGABYTE Motherboard to purchase for your Desktop PC. Order Online Or Visit your Nearest Technohouse Shop to get yours at the lowest price. The GIGABYTE H610M K DDR5 Motherboard comes with a 3-year warranty.
